| Specification | Details |
|---|---|
| Model | PA-7080 |
| Firewall Throughput (App-ID Enabled) | 200 Gbps |
| Threat Prevention Throughput (DSRI Enabled) | 160 Gbps |
| Threat Prevention Throughput | 100 Gbps |
| IPSec VPN Throughput | 80 Gbps |
| New Sessions per Second | 1,200,000 |
| Max Sessions | 80,000,000 |
| Virtual Systems (Base/Max) | 25/225 |
| Specification | Details |
|---|---|
| NPC Option 1: NPC-XM Option 11 | (20) QSFP+, (120) SFP+ |
| NPC Option 2: NPC-XM Option 21 | (120) 10/100/1000, (80) SFP, (40) SFP+ |
| Management I/O | (2) 10/100/1000, (2) QSFP+ high availability, (1) 10/100/1000 out-of-band management, (1) RJ45 console port |
| Storage Options | 80 GB SSD System Drive, 4x1 TB HDD on Log Processing Card |
| Storage Capacity | 2 TB RAID1 |
| AC Input Voltage (Input Hz) | 90-305Vac (47 to 66 Hz) |
| AC Power Supply Output | 2500 Watts @ 240Vac, 1200 Watts @ 120Vac |
| DC Input Voltage | -36 to -75Vdc |
| DC Power Output | 2500 watts / power supply |
| Max Current / Power Supply | 12Adc @ 240Vac In, 75Adc @ >40Vdc In |
| Power Supplies (Base/Max) | 4/8 |
| Max Inrush Current / Power Supply | 30Aac / 100Adc peak |
| Mean Time Between Failure (MTBF) | Configuration dependent; contact your Palo Alto Networks representative for MTBF details |
| Max BTU/hr | 20,132 |
| Rack Mountable (Dimensions) | 19U, 19” standard rack (32.22”H x 19”W x 24.66”D) |
| Weight (Stand-Alone Device/As Shipped) | 299.3 lbs. AC / 298.3 lbs. DC |
| Safety | cTUVus, cCSAus, CB |
| EMI | FCC Class A, CE Class A, VCCI Class A |
| Certifications | NEBS Level 3 |
| Operating Temperature | 32° to 122° F, 0° to 50° C |
| Non-Operating Temperature | -4° to 158° F, -20° to 70° C |
| Model | Firewall Throughput (App-ID Enabled) | Threat Prevention Throughput (DSRI Enabled) | Threat Prevention Throughput | IPSec VPN Throughput | New Sessions per Second | Max Sessions | Virtual Systems (Base/Max) |
|---|---|---|---|---|---|---|---|
| PAN-PA-7050 | 120 Gbps | 100 Gbps | 60 Gbps | 24 Gbps | 720,000 | 24,000,000 | 25/225 |
| PAN-PA-7080 | 200 Gbps | 160 Gbps | 100 Gbps | 80 Gbps | 1,200,000 | 80,000,000 | 25/225 |
