| Specification | Details |
|---|---|
| Model | PA-3020 |
| Firewall Throughput (App-ID Enabled) | 2 Gbps |
| Threat Prevention Throughput | 1 Gbps |
| IPSec VPN Throughput | 500 Mbps |
| New Sessions per Second | 50,000 |
| Max Sessions | 250,000 |
| IPSec VPN Tunnels/Tunnel Interfaces | 1,000 |
| GlobalProtect (SSL VPN) Concurrent Users | 1,000 |
| SSL Inbound Certificates | 25 |
| Virtual Routers | 10 |
| Virtual Systems (Base/Max) | 1/6 |
| Security Zones | 40 |
| Max. Number of Policies | 2,500 |
| Specification | Details |
|---|---|
| I/O | (12) 10/100/1000, (8) SFP optical gigabit |
| Management I/O | (1) 10/100/1000 out-of-band management port, (2) 10/100/1000 high availability, (1) RJ-45 console port |
| Storage Capacity | 120GB SSD |
| Power Supply (Avg/Max Power Consumption) | Single 250W AC (150/200) |
| Max BTU/hr | 683 |
| Input Voltage (Input Frequency) | 100-240VAC (50-60Hz) |
| Max Current Consumption | 2A@100VAC |
| Max Inrush Current | 0.4 A @ 230 VAC, 0.96 A @ 120 VAC |
| Rack Mountable | 1U, 19" standard rack |
| Dimensions (HxDxW) | 1.75"H x 17"D x 17"W |
| Safety | UL, CUL, CB |
| EMI | FCC Class A, CE Class A, VCCI Class A, TUV |
| Operating Temperature | 32° to 122° F (0° to 50° C) |
| Non-operating Temperature | -4° to 158° F (-20° to 70° C) |
| Model | Firewall Throughput (App-ID Enabled) | Threat Prevention Throughput | IPSec VPN Throughput | New Sessions per Second | Max Sessions | IPSec VPN Tunnels/Tunnel Interfaces | GlobalProtect (SSL VPN) Concurrent Users | Max. Number of Policies |
|---|---|---|---|---|---|---|---|---|
| PAN-PA-3020 | 2 Gbps | 1 Gbps | 500 Mbps | 50,000 | 250,000 | 1,000 | 1,000 | 2,500 |
| PAN-PA-3050 | 4 Gbps | 2 Gbps | 500 Mbps | 50,000 | 500,000 | 2,000 | 2,000 | 5,000 |
| PAN-PA-3060 | 4 Gbps | 2 Gbps | 500 Mbps | 50,000 | 500,000 | 2,000 | 2,000 |
