Specification of Honeywell Xenon 1900GSR Barcode Scanner
| Dimensions |
104 x 71 x 160 mm |
| Weight |
147 g (5.2 oz) |
| Input Voltage |
4.0V DC to 5.5V DC |
| Operating Power |
2.3 W (450 mA @ 5V DC) |
| Standby Power |
0.45 W (90 mA @ 5V DC) |
| Host System Interfaces |
USB, Keyboard Wedge, RS-232, IBM 46xx (RS485) |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Storage Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Humidity |
0% to 95% Relative Humidity, Non-Condensing |
| Drop Resistance |
Designed to withstand 50 1.8 m (6 ft) drops to concrete |
| Ratchet Stand Resistance |
Designed to withstand 50 1.2 m (4 ft) drops to concrete on each of the faces |
| Environmental Sealing |
IP41 |
| Light Levels |
0 to 100,000 Lux (9,290 Foot-Candles) |
| Scan Pattern |
Area Image (838 x 640-Pixel Array) |
| Motion Tolerance |
Up to 610 cm/s (240 in/s) for 13 mil UPC at optimal focus |
| Focus Types |
HD Focus: H 41.4°, V 32.2°; SR Focus: H 42.4°, V 33°; ER Focus: H 31.6°, V 24.4° |
| Symbol Contrast |
20% Minimum Reflectance Difference |
| Pitch, Skew |
45°, 65° |
| Decode Capability |
Reads Standard 1D, PDF, 2D, Postal, and OCR Symbologies |
About Honeywell Xenon 1900GSR Barcode Scanner
Crystal Computers, your trusted source for high-quality computer accessories in Bangladesh, proudly presents the
Honeywell Xenon 1900GSR Barcode Scanner. This versatile scanner offers exceptional performance and durability for your scanning needs. With dimensions of 104 x 71 x 160 mm and a weight of only 147 g, this scanner is lightweight and easy to handle. It operates on a low input voltage of 4.0V DC to 5.5V DC, making it energy-efficient. The Honeywell Xenon 1900GSR
Barcode Scanner features multiple interface options, including USB, Keyboard Wedge, RS-232, and IBM 46xx (RS485), ensuring compatibility with your systems. Its robust design can withstand 50 drops in concrete, and it's rated IP41 for environmental sealing.
Equipped with an area image scan pattern and motion tolerance of up to 610 cm/s, it can read various symbologies, from standard 1D barcodes to 2D codes, PDFs, postal, and OCR symbols. Upgrade your scanning capabilities with the Honeywell Xenon 1900GSR Barcode Scanner, available at
Crystal Computers. Simplify your business operations with this reliable and efficient scanning solution.
