About the GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard
The
GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard is a fully-featured motherboard designed for Intel's 12th, 13th, and 14th Generation processors. It packs advanced features such as PCIe 4.0 support, up to 128 GB of DDR4 memory, and multiple display output options. This motherboard is great for gaming, productivity, and home PC build-ups with an exceptional balance in performance and value.
Specification
| Specification |
Details |
| Brand |
GIGABYTE |
| Model |
B760M D3HP DDR4 |
| Supported CPU |
Intel 12th, 13th, and 14th Gen Core i9/i7/i5/i3, Pentium Gold, Celeron (LGA1700) |
| Chipset |
Intel B760 Express Chipset |
| BIOS |
128 Mbit flash, licensed AMI UEFI BIOS |
| Form Factor |
Micro ATX (24.4 cm x 24.4 cm) |
| Audio |
Realtek Audio CODEC, HD Audio, 2/4/5.1/7.1-channel |
| Expansion Slots |
1 x PCIe x16 (PCIe 4.0), 2 x PCIe x1 (PCIe 3.0) |
| Memory |
DDR4, 4 slots, up to 128 GB (32 GB per DIMM) |
| Graphics Outputs |
1 x HDMI, 1 x DisplayPort, 1 x D-Sub port |
| USB Ports |
1 x USB Type-C, 5 x USB 3.2 Gen 1, 2 x USB 2.0/1.1 |
| LAN |
Realtek GbE LAN (1 Gbps/100 Mbps/10 Mbps) |
| Storage Support |
2 x M.2 PCIe 4.0 x4/x2, 4 x SATA 6Gb/s |
| RAID Support |
RAID 0, RAID 1, RAID 5, RAID 10 |
| Internal I/O |
1 x 24-pin ATX power, 1 x 8-pin ATX 12V power, 1 x M.2, 4 x SATA |
| Back Panel Connectors |
2 x USB 2.0/1.1, 1 x PS/2, 1 x HDMI, 1 x DisplayPort, 3 x USB 3.2, 1 x RJ-45, 3 x audio jacks |
| Special Features |
GIGABYTE Control Center (GCC), Q-Flash Plus, RGB Fusion |
| Bundled Software |
Norton Internet Security, LAN bandwidth management software |
Description
GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard Bangladesh
GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard is present in Bangladesh. The user will enjoy all the latest intel 12th, 13th, and 14th gen processor support with fast connectivity options along with plenty of memory. So, it would be an excellent value to anyone looking for a system which would be very capable for gaming and work.
User Experience of GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard
The
GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard has received high praise from users for easy installation, a solid build quality, and strong performance. Its support for multiple display outputs such as HDMI, DisplayPort, and D-Sub, provides flexibility, and its PCIe 4.0 support guarantees the fast transfer of data, which makes it perfect for gamers and content creators. The motherboard's BIOS is easy to use, and it supports high-capacity memory, which makes it reliable for both novice and experienced builders.
Why Choose This GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard?
The
GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard is an excellent choice for anyone looking to build a high-performance PC without breaking the bank. It offers support for Intel’s latest 12th, 13th, and 14th Gen processors, provides excellent storage options (with dual M.2 slots and SATA), and offers PCIe 4.0 for the latest GPUs and NVMe SSDs. This motherboard ensures smoother multitasking and gaming with varied connectivity options along with RAID for better storage performance. It is compatible with as much as 128 GB DDR4 memory so that it would not have issues with the demanding applications.
Main Features
- Compatibility with Intel 12th, 13th, and 14th Gen CPU; supports Intel Core i9, i7, i5, i3, Pentium Gold, and Celeron Processors LGA 1700.
- PCIe 4.0 Slot: Future-proof your system with PCIe 4.0 x16 support for high-speed graphics and storage.
- DDR4 Memory: Supports up to 128 GB of DDR4 memory, ideal for intensive applications and multitasking.
- Multiple Display Outputs: Includes HDMI, DisplayPort, and D-Sub for a flexible multi-monitor setup.
- RAID Support: RAID 0, 1, 5, and 10 for data redundancy and faster read/write speeds.
- Realtek GbE LAN: Fast and stable network connections with 1 Gbps Ethernet.
- RGB Fusion: Personalize your build with customizable RGB lighting effects.
Installation Steps of GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard
- Preparation of the Workspace: Make sure the workplace is static-free, and if possible, wear an anti-static wristband.
- Installation of the Processor: Carefully insert the Intel processor into the LGA1700 socket, making sure it aligns correctly.
- Apply Thermal Paste: If needed, apply thermal paste to the CPU for better cooling.
- Installation of Memory: Insert the DDR4 RAM modules into the DIMM slots and ensure they click into place.
- Install the Motherboard: Put the motherboard in the PC case and align with standoffs. Secure using screws.
- Connect Power Cables: Connect the 24-pin ATX power connector and 8-pin ATX 12V power connector.
- Attach Storage Devices: Connect your M.2 SSDs and SATA drives to appropriate connectors.
- Installation of Expansion Cards: Insert any expansion cards, such as a graphics card, into the PCIe x16 slot.
- Connect Internal Headers: Connect cables for front panel connectors, audio, USB, and other peripherals.
- Power Up: Boot up the system, enter the BIOS, and configure the necessary settings.
Why Buy From Crystal Vision Solution?
Crystal Vision Solution offers the
GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard at competitive prices with excellent customer service and expert support. We ensure timely delivery, secure payments, and hassle-free returns, making it easy to purchase with confidence from a trusted supplier for your PC build.
What is the Price of the GIGABYTE B760M D3HP DDR4 Micro ATX Motherboard in Bangladesh?
The latest price of
Gigabyte B760M D3HP DDR4 Micro ATX Motherboard in Bangladesh depends on quantity.
Crystal Vision Solution ensures this motherboard has the best market price in Bangladesh. Our product is 100% original and lowest price in Bangladesh. All kinds of services are the best in Bangladesh, and contact us for any information and latest price.
