About of Toa TS-690 Central
The Toa TS-690 Central Unit is a high-performance system, excellently suitable for intelligently clear and effective communication in wide spaces. Supporting various audio applications, the device is designed for easy operation with high-quality sound reproduction for every conference hall or auditorium environment.
Specification
| Feature |
Details |
| Power Supply |
100V-240V AC |
| Power Consumption |
20W |
| Dimensions |
430mm (W) x 90mm (H) x 315mm (D) |
| Weight |
4.8 kg |
| Audio Output Power |
30W RMS |
| Input |
2 x MIC/Line Inputs, 1 x AUX Input |
| Output |
1 x Audio Output, 1 x Control Output |
| Frequency Response |
50Hz - 20kHz |
| Signal-to-Noise Ratio |
> 80dB |
| Operating Temperature |
0°C to 40°C |
| Control Interface |
RS-232, Web Control |
Description
Toa TS-690 Central Unit in BD
The Toa TS-690 Central Unit is highly effective and reliable to operate audio within professional sound systems. This piece of equipment would be ideal for huge areas where quality and clear audio is required. It provides ease of integration with other audio gear and multiple ways of control.
User Experience
The Toa TS-690 Central Unit is acclaimed for its reliability and excellence in the reproduction of sound. Besides, its ease of setup ensures any downtime is minimal. This unit provides clear, consistent audio even across a huge space. It comes fitted with a web-based control interface and solid design that makes it so versatile for professional applications, ensuring seamless execution in conferences and events. This also means that either in a meeting room or an auditorium, the Toa TS-690 will always guarantee high-quality sound, hence dependable for many users.
Why Choose the Toa TS690 Central Unit?
-
Clear, quality reproduction of sound for clear communication in big venues.
-
Very easy to interface with other professional audio equipment.
-
Several control options include web-based interfaces.
-
Reliable construction for durable, long-term performance.
-
Flexible mounting options accommodate a variety of applications and audio needs.
-
Compact, lightweight, suitable for portable installations.
Installation Steps
- Unbox the Toa TS-690 Central and inspect it for any damages.
- Place the unit on a flat surface or mount it securely in a rack.
- Connect the power supply to the unit.
- Attach your input devices (microphones, audio sources) to the relevant inputs.
- Connect the output devices (speakers, amplifiers) to the audio output.
- Set up the control interface using RS-232 or web control for easy operation.
- Power on the unit and adjust settings based on your audio needs.
- Test the system to ensure optimal sound quality and functionality.
