The
Safeagle HP-SE100100C Large X-ray Screening System is a high-performance X-ray scanner that offers unmatched security screening for large-scale cargo and high-risk facilities. It's designed for the most demanding security environments. This includes border crossings, railway stations, logistics companies, and government buildings. The advanced X-ray screening system provides an ideal solution for accurate cargo inspection. The HP-SE100100C’s standout feature is its innovative switchable 4/7-colors imaging technology, which assigns distinct colors based on atomic number to help operators quickly distinguish materials and identify potential threats.
Enhanced with Safeagle’s Zeff-scan function, this system uses real-time highlighting to reveal hazardous liquids and other threats like explosives and narcotics, streamlining threat identification for operators. The dual-energy X-ray technology ensures precise recognition, displaying organic materials like plastic and cloth in orange, while metals such as weapons appear in blue. This targeted color coding allows for efficient sorting, identification, and real-time threat assessment, boosting inspection accuracy and speed.
The HP-SE100100C also supports customizable split-screen and full-screen viewing for a versatile monitoring experience. With a large tunnel size and heavy-duty conveyor, it’s built to handle high cargo volumes, enhancing workflow without sacrificing security.
Safeagle HP-SE100100C Large X-ray Screening System Specifications
| Feature |
Details |
| Tunnel Size |
1001 mm (W) x 1001 mm (H) |
| Dimensions |
3036 mm (L) x 1420 mm (W) x 2015 mm (H) |
| Conveyor Max Load |
250 kg |
| Belt Speed |
0.23 m/s, bidirectional |
| X-ray Generator Voltage |
140 kV (optional: 160 kV) |
| Wire Detectability |
40 AWG |
| Spatial Resolution |
1.0 mm horizontal, 1.0 mm vertical |
| Steel Penetration |
36 mm steel, typical |
| Tube Current |
0.7 mA |
| Cooling System |
Sealed oil bath with forced air |
| Beam Direction |
Diagonally upward |
| Dual-Energy |
Yes |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Storage Temperature |
-20°C to 60°C (-4°F to 140°F) |
| Humidity |
Up to 95% non-condensing |
| Power Requirements |
220 VAC ±10%, 50/60 Hz, 10A max |
Key Features
- Switchable 4/7-Color Imaging: Provides high clarity, with each color assigned to a specific atomic range for precise threat detection.
- Real-Time Zeff Scan Function: Automatically highlights explosives, narcotics, and other hazardous substances during scans.
- Dual-Energy X-ray Technology: Clearly distinguishes materials by atomic number, allowing for quick identification of organic and inorganic materials.
- Split-Screen & Full-Screen Options: Operators can customize viewing preferences for improved scanning efficiency.
- Heavy-Duty Conveyor: Supports up to 250 kg, ideal for high-capacity cargo and parcel screening.
Applications
- Airports and Cargo Terminals: Ensuring safe, accurate screening of large baggage and cargo.
- High-Security Installations: Effective at screening in government, military, and other high-risk environments.
- Logistics & Transport Centers: Efficiently screens large cargo volumes at shipping hubs.
- Customs and Border Control: Provides advanced security screening at border checkpoints.
