| Image Sensor |
1/2.5” 8Megapixel progressive scan CMOS |
| Effective Pixels |
3840(H)x2160(V) |
| RAM/ROM |
512MB/32MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual, 1/3(4) ~1/100000s |
| Minimum Illumination |
0.06Lux/F1.6(Color,1/3s,30IRE) |
|
0.3Lux/F1.6(Color,1/30s,30IRE) |
|
0Lux/F1.6(IR on) |
| S/N Ratio |
More than 50dB |
| IR Distance |
Distance up to 40m (131ft) |
| IR On/Off Control |
Auto/Manual |
| IR LEDs |
2 |
| Lens |
|
| Lens Type |
Fixed |
| Mount Type |
Board-in |
| Focal Length |
2.8mm (4.0mm optional) |
| Max. Aperture |
F1.6 (F1.6) |
| Angle of View |
H:112° (88°), V:69° (48°) |
| Optical Zoom |
N/A |
| Focus Control |
Fixed |
| Close Focus Distance |
0.9m(1.7m) |
| DORI Distance |
|
| Lens |
Detect |
|
Observe |
|
Recognize |
|
Identify |
| 2.8 mm |
69m(226ft) |
|
28m(92ft) |
|
14m(46ft) |
|
7m(23ft) |
| 4.0 mm |
89m(292ft) |
|
36m(118ft) |
|
18m(59ft) |
|
9m(30ft) |
| Pan/Tilt/Rotation |
|
| Pan/Tilt/Rotation Range |
Pan:0˚360˚; Tilt:0˚90˚; Rotation:0˚~360˚ |
| Intelligence |
|
| IVS |
Tripwire, Intrusion, Object Abandoned/Missing |
| Advanced Intelligent Functions |
Face Detection |
| Video |
|
| Compression |
H.265+/H.265/H.264+/H.264 |
| Streaming Capability |
3 Streams |
| Resolution |
4K, 6M, 5M, 3M, 1080P, 720P, D1, VGA, CIF |
| Frame Rate |
Main Stream: 4K(115fps), 3M(125/30fps) |
|
Sub Stream: D1(1~25/30fps) |
|
Third Stream: 1080P(1~25/30fps) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 24K ~ 10240Kbps |
|
H.265: 14K ~ 9984Kbps |
| Day/Night |
Auto (ICR) / Color / B/W |
| BLC Mode |
BLC / HLC / WDR (120dB) |
| White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detection |
Off / On (4 Zone, Rectangle) |
| Region of Interest |
Off / On (4 Zone) |
| Electronic Image Stabilization |
N/A |
| Smart IR |
Support |
| Defog |
N/A |
| Digital Zoom |
16x |
| Flip |
0°/90°/180°/270° |
| Mirror |
Off / On |
| Privacy Masking |
Off / On (4 Area, Rectangle) |
| Audio |
Compression: N/A |
| Network |
|
| Ethernet |
RJ-45 (10/100Base-T) |
| Protocol |
HTTP, HTTPS, TCP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, QoS, UPnP, NTP, Bonjour, 802.1x, Multicast, ICMP, IGMP, SNMP |
| Interoperability |
ONVIF, PSIA, CGI |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
10 Users / 20 Users |
| Edge Storage |
NAS, Local PC, Micro SD card 128GB |
| Web Viewer |
IE, Chrome, Firefox, Safari |
| Management Software |
Smart PSS, DSS, Easy4ip |
| Smart Phone |
IOS, Android |
